1NSSAveri - 1981 Bristol 41.1 Aft Cockpit Cutter

LOA(incl. pulpit) - 13.7 m

LWL - 11 m

Beam - 3.9 m

Displacement - 12034 kg

Ballast - 4763 kg

Draft (Min) - 1.5 m

Draft (Max) - 3.3 m

Bridge Clearance - 18.5 m


Displacement to Length Ratio - 320.7


Sail Area Displacement Ratio - 14.6


Theoretical Hull Speed - 8.2 kt


Berths for 5 (cozy 6)

Sail compliment – Main - 36 m²

                                 Genoa - 46.5 m²

                          Yankee Jib - 19.5 m²  on roller furling

                     Inner Staysail - 11 m²  on roller furling

    Spinnaker, Asymmetric - 63 m²

                       Storm Trisail - w/ separate track

Ground Tackle

        Main anchor - 33 kg Rocna on 107 m, 9.5 mm  Grade 42 Chain

        Secondary     - 27 kg CQR on 46 m, 8 mm  Grade 42 Chain

        Emergency    - 20 kg Danforth on 91.5 m, 19 mm  double braid nylon rode


        Backup           - 15 kg Danforth

        Para Anchor  - 5.5 m parachute w/ 91.5 m, 19 mm   double braid nylon rode


        Maxwell VWC 1500 Windlass

Hydrovane wind steering

        w/ spares kit

Engine/Drive

        55 hp Isuzu

        Fuel Boss filter system w/ dual Racor filters

        170 liter diesel tank  (4 x 20 liter Scepter Military fuel cans)

        43 cm  Max Prop folding prop

Electrical

       Batteries, House bank (6 – 110amp Carbon Foam )

                         Engine bank (1 – 450 CCA AGM)

       4 - 100 watt solar panels, single crystal rigid (Grape Solar) on a Blue Sky 2512iX controller

       4 - 100 watt solar panels, single crystal semi flexible on a Victron 100/50 controller

       1 - 400 watt wind generator, SilentWind

       120 amp engine alternator (85 amp back up) with a Balmar MC-614 Regulator

       Outback, Charger Inverter, 40 amp AC output, true sine

       LED lighting

Instrumentation/Electronics

       Simrad Radar (3G) and Chartplotter (NSS7)

       NavMan GPS Chartplotter

       Furuno GPS, Depth, Fluxgate Compass and Autopilot

       ICOM SSB w/ AT-140 tuner

       ICOM M-424 VHF w/ DSC

       Standard Horizon AIS and VHF w/DSC

       ASI Graphing Barometer

       Dragon 4 Pactor Modem

       AIRMAR Depth, Temp and Speed transducer

       AIRMAR Wind and Weather Sensor


      Actisense NGT and NGT1 for NEMA 0183 to 2000 conversion and 2000 to USB.

Plumbing/Heat

       208 liter main water tank

       2- 57 liter reserve water tanks

       EC02 Tech 49 liter/hr. watermaker

       22 liter water heater

       95 liter Holding tank

       Eberspacher Airtronic D4 diesel heater

Galley

       .25 m³ Frigoboat freezer


       Isotherm -0.1 m³ refrigerator drawer

       Tasco 3 burner stove with oven

       Double sink

       Magma LP grill

       4 – 4.5 kg LP gas bottles

Safety

      Winslow 6 man life raft

      ACR 406 GPS EPIRB

      ACR Personal EPIRB

      Ditch Bag and Extra Emergency Rations Bucket

     Off shore vests w/ harnesses and strobe

      Dynema Jack lines

      Throwing float w/ strobe

      COB float w/ pole and flag

      Lifesling recovery float

      2 – Auto fire extinguishers, 4 – manual (2x5 and 2x10)

      Smoke, CO and LP sensor alarms

      Fire blanket at galley

      Comprehensive first aid kit

      Edson 3.78 liter / stroke manual pump

      3 electric bilge pumps with 7500 liter/ hr. back up pump

Tender

3 meter AB RIB w/ 15hp. outboard




Sailing AVERI


“A person who never made a mistake, never tried anything new.” - Albert Einstein

Marc and Nicola

This is a brief outline of Averi and what we have aboard. I will continue to flesh it out and will give some information on things we found to work and things that didn't on the "Pieces and Parts" page.
